First NASA Juno Mission’s close-ups of the Great Red Spot are here

Details in the Great Red Spot that have never been seen before are now visible, thanks to the first images available from Juno’s seventh PeriJove flyby of Jupiter. Image credit: NASA / JPL-Caltech / SwRI / MSSS; processing by Ethan Siegel.

After a generation, we’re finally getting another close-up view. With the science we’re learning, we just might solve its mysteries.


“Jupiter instead cooled down below the threshold for fusion, but it maintained enough heat and mass and pressure to cram atoms very close together, to the point they stop behaving like the atoms we recognize on earth. Inside Jupiter, they enter a limbo of possibility between chemical and nuclear reactions, where planet-sized diamonds and oily hydrogen metal seem plausible.” –Sam Kean

NASA’s Juno mission has been in orbit around Jupiter, the Solar System’s largest planet, for over a year now. During this time, it’s taken pictures of the cloudtops, poles and bands on Jupiter as never before, with more advanced instruments and cameras and also from closer distances than any other spacecraft in history. With eight different instruments designed to measure various properties and layers of Jupiter’s atmosphere, plus an imager known as JunoCam, we’ve been able to image the swirling, turbulent clouds like never before.

An image of Jupiter’s cloudtops as seen during a previous Perijove encounter, stitched together to provide a partial view of the planet. Image credit: NASA/SWRI/MSSS/Gerald Eichstadt/Sean Doran.

But the greatest storm-of-interest on Jupiter has got to be the Great Red Spot, a giant hurricane that’s endured for at least 177 years, and possibly many hundreds more. Although it’s changed its size extent many times, it’s still more than twice the size of the entire Earth, and its reddish color is one of the mysteries that Juno’s scientific instruments will seek to solve. Previously, however, our closest view of it came from Voyager 1, which flew within about 277,000 kilometers (172,000 miles) of Jupiter back in 1979.

An illustration of Jupiter’s Great Red Spot, as seen by Voyager 1, with the shadow of Juno superimposed, to showcase what scientists were expecting to conceivably see during last Monday’s fly-by. Image credit: NASA / JPL / Björn Jónsson / Seán Doran.

Juno, on the other hand, makes an elliptical orbit that takes it extraordinarily close to the top of Jupiter’s atmosphere. On Monday June 10th, Juno made its seventh closest-approach-pass to Jupiter, known as Perijove, where it came within 3,500 kilometers (2,200 miles) of the edge of the atmosphere. As it dips down low, some new, interesting features can be observed.

The two storms clearly visible here may last anywhere from hours to years, and yet are far faster than any storm or atmospheric phenomenon ever seen on Earth. Image credit: NASA / SwRI / MSSS.

What you see here are hurricane-style storms, swirling at up to 600 kilometers-per-hour, that will last anywhere from hours to years in the turbulent environment of Jupiter. Juno’s unprecedented proximity to Jupiter allows it to pick up features that even Hubble cannot see. When the scientific data is analyzed, we’ll be able to learn the temperature, composition, wind speed, depth, and many other properties about these features.

Complex, turbulent features in Jupiter’s atmosphere are revealed in great detail, but the images during PeriJove are distorted due to the reduced field-of-view of Juno thanks to the planet Jupiter itself. Image credit: NASA / SwRI / MSSS.

However, Juno gets so close to Jupiter that its actual images appear distorted, in this pinched-hourglass shape. According to NASA,

JunoCam images of Jupiter sometimes appear to have an odd shape. This is because the Juno spacecraft is so close to Jupiter that it cannot capture the entire illuminated area in one image — the sides get cut off.

Just a few minutes after Monday’s closest approach, Juno flew over the Great Red Spot, at an elevation of only 9,000 kilometers (5,600 miles). The three raw images that came back contain a huge amount of information within them.

The turbulence of the spot can be seen quite dramatically here, as Juno moves towards the South Pole of Jupiter in its orbit, as the next two images show. Image credit: NASA / SwRI / MSSS.

Taken in red, green, and blue filters, and then stacked together to make a composite, color image, these three images combined provide total coverage of the Great Red Spot.

The Great Red Spot, in the middle of a JunoCam image, along with the wake it produces towards the equatorial side. Image credit: NASA / SwRI / MSSS.

The raw data is freely available from NASA, and showcases not only the three different views, but the surrounding bands and regions as seen by Juno.

The atmospheric flow around the lower section of the Great Red Spot, along with the fractured boundary layer beneath. Image credit: NASA / SwRI / MSSS.

Hanging around and waiting for the scientific analysis will be incredibly informative, but this raw data contains so much useful information on its own that image processing can really bring out some tremendous details here.

Combining Juno’s three main images of the Great Red Spot and enhancing the color and contrast has yielded a spectacular view of the Great Red Spot. Image credit: NASA/JPL-Caltech/MSSS/SwRI/Kevin M. Gill.

An enhanced-color view will showcase the relief and contrast between the eye of the storm and the rest of Jupiter’s atmosphere.

The Great Red Spot from Juno, with additional image processing. Image credit: NASA / SwRI / MSSS / Gerald Eichstädt / Seán Doran.

You can clearly see eddies and turbulence at play inside the Great Red Spot itself, which comes about by filling with the color saturation and the contrast.

Even though the unprocessed image appears washed-out and unimpressive to the naked eye, much useful information is encoded in here, and can be drawn out by tweaking the image controls. Image credit: NASA / JPL-Caltech / SwRI / MSSS; unprocessed.

Unprocessed, raw images are available, but after playing with some of the image processing knobs myself, I was able to expose some incredible details in the Great Red Spot, at resolutions never seen before today.

Additional details in the Great Red Spot, including eddies and turbulent atmospheric features, can be seen simply by fiddling with some basic image processing parameters. Image credit: NASA / JPL-Caltech / SwRI / MSSS; processing by Ethan Siegel.

Three of my favorite views, however, are already publicly available on the NASA/Juno website, with more to come.

The atmospheric flow and fractured boundary around the Great Red Spot, as imaged by Juno and processed using GIMP. Image credit: NASA / JPL-Caltech / SwRI / MSSS; processing by Tatsuo-36.

Processing includes sharpening, contrast, color, saturation, hues, and much more.

The great red spot in all its beauty seen by the JunoCam, image process to intensify the beauty of the bands and zones of Jupiter. Image credit: NASA / JPL-Caltech / SwRI / MSSS; processing by Carlos Galeano — Cosmonautika.

Boundary layers in the atmosphere, as well as a variety of features in the spot itself, are exposed through these various techniques.

Improved saturation and increased detail of Jupiter’s atmosphere. Greater sharpness along with proper curve processing allows you to see more details also of the great red spot and other storms on the planet. Image credit: NASA / JPL-Caltech / SwRI / MSSS, processing by Rhondastroud-49.

With new images still coming in, and all the science still to come, these first views are only a tantalizing hint of what secrets the largest, most massive world in our Solar System is sure to reveal as Juno’s mission continues.
